PCBA Services
Professional PCBA factory, provide PCBA production, PCBA fast-turn sample and SMT production.
PCBA Production process:
Production Capability:
|
SMT项目 SMT Item |
中小批量能力 small&middle batch capability |
样品（20pcs内） sample(within 20pcs) |
|
最小chip零件 min. chip packaging |
1005封装及以上 1005 packaging and above |
1005封装及以上 1005 packaging and above |
|
最大零件尺寸 max.components dimension |
150mm*150mm | |
|
最小引脚零件间距 min.pin spacing |
0.3mm | 0.3mm |
|
最小球状零件（BGA）间距 min. BGA spacing |
0.3mm | 0.3mm |
|
贴片能力 Assembly capability |
300-400万点/日 3-4 million points/day |
|
|
DIP插件加工 DIP |
10万点以上 above 10 million |
Information Required By The Client
- Precision BOM list
- Gerber file, if need stencil with panelisation, pls provide panelisation file
- Components location drawing
- Coordination file
- Prototype or prototype photo
Material requirements
- Customer prepare material by themselves, and provide sparing
- Indicate the area which no need do soldering
- Any special requirement and note pls advise us in advance
- Provide stencil, soldering fixture, testing fixture
Customer service
- Only for the issues which raised within 30 days
- Only soldering issue for incoming material
- Assume one way freight cost
Package type:
PCBA: Bubble film+foam + carton packaging
| carton packaging | ||
| L（CM） | W（CM） | H（CM） |
| 31.00 | 26.00 | 25.00 |
| 26.00 | 21.00 |
19.00 |
Any special requirement and note pls advise us in advance
Equipment
